100BC0003, Opti-Luxx Low Profile Clear LED Strobe Beacon

• 100BC0003
• Plug and play compatible with existing 3-hole beacon mounting patterns
• Center drop wire for ease of installation
• Best in class optics provides light output that meets SAE J845 Class 1 requirements
• 360 degree illumination provides outstanding visibility from all angles
• Adhered base gasket assures a water tight seal to the vehicle without the use of sealants
• Flash Patterns: Double, Triple, Quad, Rotating
• Input voltage range: 10-30 Volts
• Current Draw: 1.35/1.85A (min/max)
• LED Count: 12
• Operating Temperature: -40 Celsius to +65 Celsius
• Dimensions: Height - 3.19" (81mm), Diameter - 6.7" (170.9mm)
• Mounting: Surface Mount, 3 Holes on 5.99" (152.1mm) circle dia. Permanent (screw) Adhered EVA gasket
• Certifications: SAE J845/J2139 Class 1 FMVSS/CMVSS 108 IP Code IP67
• Warranty: 5 years

Cross Number's

100BC0003-A,BB10071825,10071825,3891418C2
