1-1080-1106, Weldon Red 2 Wire Halogen Warning Light 1080 Series

• 1-1080-1106
• 7" Red Halogen Overhead Warning Light
• 2 Wire
• Flat back
• Original school bus warning lights equipment for major school bus builders
• No need to cut clearance holes
• Depth: 2.0 inches (50.8 mm)
• Diameter: 7 inches (178 mm)
• Wattage: 55
• Volts: 12.8
• Amperage: 4.6
• 5 year warranty against defects in materials or workmanship

Red Stainless Steel 2 Wire Halogen Warning Light 1080 Series: 1-1080-1106

Weldon Warning Lights

Service Parts:

• Lens: OC11-1183
• Mounting Gasket: 1018
• Bulb: H-3
• Lens Gasket: OD10-1185-00
• Visor: 1021
• For use with the 7000 8 Lamp Flasher

These 7” diameter school bus lights surface mount to a vertical, planar vehicle surface using 4 customer supplied #8 or #10 screws on a 6.25” bolt circle.  The lamp includes a 10 mm thick closed cell foam pad that compresses to seal between the lamp body and the mounting surface.  Wire exit into the vehicle must be placed so that lead wires can pass directly from the lamp through the mounting surface without being pinched.  All holes for passing wires must use a protective grommet. The lamp complies with SAE J887 and all associated weathering tests as required by FMVSS108 for pupil warning lamps. An H3-55W halogen bulb along with a metalized reflector and specific optical lens combine to meet the photometric requirements of J887. Lamp mounting torque is recommended from 12 to 20 in-lbs. Exceeding 20 in-lbs can deform the lamp’s steel housing and create a leak path.

Weldon Part#: 1080-1106-10

Cross#'s: 5200-4799, W1080R-2, 110801106, WEL-110801106, WTE 1080 1106 10, 52004799, 52005600, ST92RBP
